The Eyring Model

Fred Schenkelberg
3 min readJul 3, 2017

--

The Eyring Model for Accelerated Testing

Sometimes the reaction rate of a process relies on two stresses. For chemical reactions temperature seems to influence the rate of the reaction. Yet, other stresses such as humidity or voltage may also play a significant role.

H. Eyring suggested a model that assumes the contribution of each stress on the reaction rate is independent thus one could multiple the respective stress contributions to the rate of reaction.

The Erying model provides a means to account for the contributions of temperature and another stress when modeling the time to failure of select failure mechanisms.

The Erying Model General Form

The model includes the Arrhenisus model for the temperature contribution, and an inverse power law term for another stress.

The general form of the model is:

Erying Model General Form

Where

t is time (nominal product life)

A and B are constants related to the specific process being modeled

S is the applied stress

Ea/kT is the activation energy divided by Boltzmann’s constant and temperature in Kelvin

Note the stress, S, may be transformed any number of ways such as inverse, squared, or square root.

A generalized form of the model include an interaction term to account for any interaction between temperature and the additional stress.

Two Stress Erying Model

Where

C is another constant

D is a constant and represented the interaction term

Four Uses of the Erying Model

Nelson used the Erying model to model capacitor life using the natural log (ln) of the voltage stress.

Black modeled electromigration in aluminum conductors in VLSI and other microelectronics using temperature and current density.

Peck modeled failures of electronics epoxy packaging using temperature and relative humidity.

--

--
